Tmteck gloss meter TM8880 Gloss measurement instrument 20 60 85
- Gain the first- class China Metrology Accreditation.
- Chinese and English switchover operations.
- To meet the measurement of the gloss in any case.
- Multi-angle precise test and stable property.
- Shape design with the international fashion.
- Unique technological means and guarantee the favorable repeatability guaranteed
Professional design standard,and powerful functional configuration
This instrument conforms to the Test Conditions stated in lSO 2813,and meets the test requirements under different gloss conditions. With the powerful functions, large data storage is available, and it can allocate the storage data structure freely. It stores the mass data backup through SD card or conducts the data backup by adopting PC connection. The overvoltage protection function realizes the automatic power-off under the abnormal situation of the voltage, for fear of the damage of the instrument.The function of updating at any time by the instrument operational software facilitates the updating maintenance of the software, which can guarantee that the operational software keeps the latest version all the time
Unique technological means,and guarantee the favorable repeatability guaranteed
Conform to Test Conditions stated in Iso2813 and to measure the gloss data from20°, 60° and 85° these three angles at the same time.
PC software, data statistical management
Low power, full data hint
Mass data storage of SD card
USB and Bluetooth (optional) data connection
To connect the mini-printer for printing
Fit for enterprise internal and external gloss evaluation and data control
Technical Parameters
|
Measuring angle |
20″,60°,85° |
|
Measurement of spot size |
20°:10×10 mm 60°:9×15 mm85°:5 × 38 mm |
|
Storage |
100 sets of standard samples, storing 100 sets of testing samples,under each standard sample, with free allocation |
|
Conformity |
IsO 2813、ISO 7668、ASTM D 523、ASTMD 2457、DIN 67 530、JIS Z8741、BS 3900、BS 6161 |
|
Measuring time |
0.5 seconds |
|
Measuring range |
20°:0.0~2,000 Gu 60°: 0.0~1,000 Gu 85°:0.0~160 GU |
|
Measuring mode |
Sample measuring,statistical measuring, continuous measuring.and basic measuring |
|
Resolution ratio |
0 ~ 99.9 GU:0.1 GU100~2 000 GU:1 GU |
|
Power Source Management |
The function of automatic backlight off,Automatic power- off |
|
Repeatability |
0.0~99.9 Gu: 0.2 GU 100~2,000 GU: 0.2% of indication |
|
Interface Language |
Chinese and English |
|
Power Source |
External direct current +5V power adapter / USB/ Four 1.5V alkaline batteries or nickel- metal hydride batteries |
|
lndication error |
0.0~99.9 GU: 1.5 GU100~2,000 GU:1.5% of indication |
|
Port |
USB 2.0,Bluetooth standard edition 2.0 |
|
Weight |
520g |
|
Size |
163.8×58.1×88.3mm |
