TS24 Deep Penetrating Probe

Short Description:


Product Detail

Product Tags

TS24

Deep Penetrating Probes:Low frequency with strong sound penetration,suitable for detecting thick parts

Advantages

1.High compatibility, can be compatible with most phased array flaw detectors.

2.Weld penetration deep penetration series.

3.Acoustically matched to Rexolite for most angle beam.

Application

1.Thick plate material and weld

2.Forgings, noise or granular materials

3.Moderate constitution and large monitoring range

Probe
Series

Model

Element
 Shape

Freq (MHz)

E-Nos

Pitch
(mm)

Active
Aperture

(mm)

Elev.(mm)

Size(LxWxH )

TS24/A5

1.5L32-0.75×24

Linear

1.5

32

0.75

24.0

24.0

29x43x25

(mm)

1.14×1.69×0.98

(in)

2.25L16-1.5×24

Linear

2.25

16

1.50

24.0

24.0

2.25L32-0.75×24

Linear

2.25

32

0.75

24.0

24.0

5L16-1.5×24

Linear

5

16

1.50

24.0

24.0

5L16-1.2×20

Linear

5

16

1.20

19.2

20.0

5L32-0.6×20

Linear

5

32

0.60

19.2

20.0

*The standard cable length is 2.5m/8.2ft. The phased probe can be customized,include frequency, element number and pitch,etc.



Wedge Specification

Probe Series

Model

Compatible Model

Element  Shape

Size(LxWxH)

TS24/A5

N0L 0°LW -30°~30°

29x43x25

(mm)

1.14×1.69×0.98

(in)

N45L 45°LW 40°~70°
N60L 60°LW 40°~70°
N45S 45°SW 40°~70°
N55S 55°SW 40°~70°
N60S 60°SW 40°~70°
N60-IHC 60°SW 40°~70°
N60S-AOD100 60°SW 40°~70°
N60S-IHC-AOD100 60°SW 40°~70°

Quick Details

Model Number:5L32-0.6×20-TS24/5L32-19.2x20-A5

Element:32

Element Shape:LinearSize:LxWxH29x43x25(mm)1.14×1.69×0.98(in)

Warranty:12 Months

Case:Stainless steel

Application:Thick plate material and weld

Customization:yes

Type:phased array probe

Color:Silver

MOQ:1

NDT certificate

NDT1

NDT2
